I/O System S900 Digital I/O Modules DO910 and DX910 The technical data in the data sheet (catalog) only applies to channels without load respectively for situations where all channels are loaded within the valid range. Short-circuits an all other channels results in a load curve on the remaining channel that is approximately 40% lower. Switching performance (input) The following figure shows the load curve of the module when using it as an input. Connected sensors according to the standard mentioned above will always be within the ON or OFF ranges, their switching point is sufficiently far from the module's switching threshold, so that safe detection is always guaranteed. If other sensors are to be connected, make sure that the characteristic curve is within the ON or OFF ranges. For a simple contact this is not the case, as the load resistance is either infinite (switch open) or close to 0 (switch closed). When deactivating the line-break and short-circuit monitoring, • the short-circuit range goes to the ON condition (“1”), • the line-break range goes to the OFF condition (“0”). Connecting a switching contact deactivates the line-break and short-circuit monitoring. In addition, each input can be debounced. To be able to use line-break and short-circuit monitoring even with simple contacts, the signal level could be matched accordingly by additional resistors.
