For output channels, line monitoring is only active when the channel outputs “1”. Table 3-1 Conditions valid for the detection of line-break and short-circuit DO910 DX910 Line-break i < 0.5 mA i < 0.12..0.2 mA Short-circuit R < 176 Ω* R < 300..350 *) The voltage of the channel concerned (=output channel) is pulsed at approximately 1 kHz to prevent overloading the module by the short-circuit current. With software version 1.10 of the module, pulsing is only done when short-circuit monitoring is activated. From software version 1.41 onwards, this function is independent from monitoring.

Selection criteria for loads with ohmic resistance (e. g. relay coil): • 1100 Ω < R < 40 kΩ • UN min < 8 V • IN min < 4 mA • PN min < 17 mW Selection criteria for non-linear loads (e. g. optocouplers): • Determine the input characteristic curve of the load. • The intersection of the input curve and output load curve must be within the permissible range (ON). • The intersection must not be less than the nominal voltage of the load. • The intersection must not be less than the nominal current of the load. Line monitoring The modules described monitor the lines to the connected actuator / sensor. Line monitoring can be deactivated.
