3HAC025724-001/04

AMIKON LIMITED

Sales Manager:Nancy

Email:info@amikon.cn

Wechat + 8618020776786

Skype:onlywnn_1

Website: www.amikon.cn

Advantage Brands:

Allen Bradley: Reliance,SLC500/1747/1746,Logix5000/1756,PLC-5/1771/1785

ABB: DSQC series,H&B Freelance,Bailey

Bently Nevada: 3500 System spare parts ,3300 System spare parts

Yokogawa DCS

Honeywell DCS

Ovation: 1C31234G01/1C31227G01/1C31166G01/1C31116G01/1C31189G01 etc DCS System spare

GE: IC693/IC697/IS200/DS200/IS215

Triconex: 3700A/3805E/3604E/3503E/3504E/3008/4119A/8312/3703E/3511/

Schneider 140 PLC series 140CPU67160/140CRP93200/140CPS11420

AMIKON LIMITED to the "professional, integrity, innovation, cooperation, win-win"

business philosophy, and constantly develop new products, to provide quality services, in order

to maximize the pursuit of customer satisfaction, and constantly open up new areas of business for customers.

Example 2: The following information is found on the rating plate of a relay: UN =12 V (+/- 10%) IN =40 mA The internal resistance is 300 Ω. In switched-on condition this will result in an operating point of approximately 12 V and 40 mA. This operating point exactly matches the rated data of the relay. Due to the relatively lower resistance and the inherent high power consumption (in relation to the valve in example 1), the number of plug-in modules in an S900 station is reduced (for details regarding the maximum number of I/O modules refer to the mounting and installation instruction of the S900 I/O system). The module is used for connecting contactless sensors or initiators according to IEC60947 (Low-voltage switchgear and control gear, Part 5-6:. Control circuit devices and switching elements – DC interface for proximity sensors and switching amplifiers (NAMUR)) or DIN60947, respectively. Alternatively potential-free contacts can be connected and evaluated by the module. External power supply is not required, as it is provided by the module itself. When using the module as output, intrinsically safe low power valves or optocouplers can be used, for example. Observe the common electrical interconnection of the channels. This means that only potential-free sensors, contacts, and valves can be connected.
