Below a current of approximately 1 mA a wire-break is reported. Wire-break monitoring can be deactivated. If the voltage across the load falls below 5 V, a short-circuit is reported. Short-circuit monitoring can be deactivated. Selection of suitable valves / relays • For Umax < 27 V connect to terminal pair B, otherwise to A • Ri > 1500 Ω* • UN < 26 V *Although it is possible to connect devices with an internal resistance as low as 270 Ω, this will reduce the number of plug-in modules of the S900 station.

Example 1: The following information is found on the rating plate of a valve: UN =7 .. 34 V IN =4.3 .. 25 mA PN =30 .. 850 mW The internal resistance is approximately 1.5 kΩ. In switched-on condition this results in an operating point on curve A at approximately 21 V respectively 16 V on curve B. The valve can be connected to both terminal pairs, as the maximum permissible nominal operating voltage is 34 V. When connecting to B, the output is already within the voltage limit. This does not influence the power dissipation of the module.
