5 work station end forming machine
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Max pipe dia
φ30mm(copper ,aluminum)
Max work thickness
2.5mm
Work station
1
Work efficiency
3-6sec/cycle
Electric control mode
PLC
Operation mode
Auto / manual / jog
Loading mode
Manual
Driving mode
hydraulic
Work mode
Cool upending and spinning
Heading travel
100mm ( adjustable )
Max clamping force
4000kg
Max clamping travel
50mm
Max stress
4000kg
Tolerance of depth
‹ 0.5mm
Tolerance of coaxial
‹ 0.1mm
Power
3 phase 350V50HZ
Hydraulic motor power
3.75kw
Hydraulic system pressure
8Mpa
Notice: Specific technical parameters is according to order contract
