Parts | Specification | FY-1B | FY-1T |
Head | Binocular head | ● | / |
Trinocular head | / | ● | |
Microscope Main Body | |||
Optical System | Infinity optical system | ● | ● |
Total Magnification | 40X-1600X | ● | ● |
Eyepiece | Plan P10x/φ18mm | ● | ● |
Plan P16x/φ14mm | ● | ● | |
Viewing Head |
Infinity compensation binocular head, inclined 30°,
interpupillary distance 55-75mm, 360° rotatable. |
● | |
Infinity compensation trinocular head, inclined 30°,
interpupillary distance 55-75mm, 360° rotatable. |
● | ||
Nosepiece | 4 Holes revolving nosepiece, inward | ● | ● |
Fluorescence
Free Objective |
FL4X | ● | ● |
FL10X | ● | ● | |
FL40X(S) | ● | ● | |
FL63X(S) | |||
FL100X(SO) | ● | ● |
Items Spec and Parameter XSZ-HY1 XSZ-HY2 Order No. Main body / ● ● MS50Xb Eyepiece Plan 10X-18 ●● ●● EP10a Plan 16X-10 ●● ●● EP16a S-plan objective S-plan 4X/0.10 ● ● B-OSPr4 S-plan 10X/0.25 ● ● B-OSPr10 S-plan 40X/0.65 ● ● B-OSPr40a S-plan ...
Items Specification X-OF2 Eyepiece WF 10X-18mm ●● WF 10X-20mm ○○ WF16X-13mm ○○ WF 10X-18 mm (Reticule 0.1mm) ○ Infinity E-Plan Objectives Plan 4X ● Plan 10X ● Plan 20X (S) ○ Plan 40X (S) ● Plan 100X (Oil) (S) ● Main Body / ● Fluorescence Attachment Epi ...
Items Specification X-OF12 X-OF14 Eyepiece WF10×-20 mm ●● ●● WF16×-13 mm ○○ ○○ WF10×-20 mm (Reticule 0.1mm) ○ ○ Infinity Plan Objective 4× ● ● 10× ● ● 20×(S) ● ● 40×(S) ● ● 100×(Oil)(S) ● ● Seidentopf Binocular Head Inclined ...
FY-2 Epi-Fluorescence microscope include fluorescence light and transmitted bright field light system, can be widely used in all kinds of basic theories research and clinical diagnosis, like biology, cytology, histology, oncology, genetics, and immunology. ◆Normal light and ...
