MIC-JY7 fluorescent microscope
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
| Specification | |
| Optical system | infinite optical system |
| viewing head | Compensation Free Trinocular Head Inclined at 30°(50mm-75mm) |
| Eyepiece | PlanWF10×/22mm |
| Objective |
infinite Plan large N.A fluorescent objectives
4×/0.15（W.D.=21.6mm) 10×/0.35（W.D.=2.9mm） 20×/0.60（W.D.=1.5mm） 40× /0.75（W.D.=0.6mm） |
| Nosepiece | Sextuple Nosepiece |
| Stage | Double layer mechanical stage |
| Stage Size：180mm×160mm | |
| Moving Range ：80mm×50mm | |
| Focusing |
Coaxial coarse & fine focusing adjustment,
fine focusing scale value 0.002mm |
| Light Source |
Epi-illumination:
Kohler illumination with aperture iris diaphragm and field iris diaphragm LED bulb 3V/5W,AC 85V-230V,brightness adjustable |
|
Transmission illumination:
Kohler illumination with aperture iris diaphragm and field iris diaphragm 3W LED bulb,AC 85V-230V, brightness adjustable |
|
|
Fluorescence
attachment |
G、B、BV、V、UV |
|
Optional
Accessory |
Eyepiece：WF10×/20mm,WF20×/12.5mm |
| Objective:infinite Plan large N.A fluorescent objective | |
| 100x/0.90 (Dry) (W.D.=0.62mm) | |
| Photography attachment and CCD C-mount:0.5X,0.57X,0.75X | |
| Image analysis software | |
| Fluorescent digital CCD |
