Viewing Head | Compensation Free Binocular Head Inclined at 30°(50mm-75mm) |
Eyepiece | WF10×/22mm |
Objective |
Infinite Achromatic Fluorescent Objectives:
4×/N.A.O.15、10×/N.A.O.35、20×/N.A.0.6、40× (S) /N.A.O.75 |
Nosepiece | Sextuple Nosepiece |
Stage | Double layer mechanical stage |
Stage Size: 180mm×160mm | |
Moving Range: 80mm×50mm | |
Condenser | N.A.1.25 Abbe condenser with iris diaphragm and filters |
Focusing |
Coaxial coarse&fine focusing adjustment with rack and pinion mechanism.
Fine focusing scale value 0.002mm |
Light Source | Transmission Illumination: Halogen Bulb 12V/30W, Brightness Adjustable |
Epi-Fluorescent Illumination: 220V(110V) .Ultra-high pressure
Mercury Lamp100W/DC.Digital display mercury lamp constant power |
|
Fluorescent Box | G、B、BV、V、U Wave Band |
Optional
Accessory |
Eyepiece: WF16×/17mm、WF20×/12.5mm |
1.3Mega、2.0 Mega、3.0 Mega、5.0 Mega pixels CMOS Digital camera eyepiece | |
Infinite Plan Objectives: 4×,10×,20×,40×(s),60×(s),100×(s)oil | |
Infinite fluorescent Objectives:100×(dry)/N.A.0.9 | |
Y Wave band fluorescent box | |
Light Source: Halogen Bulb 12V/50W,12V/100W | |
Photography attachment and CCD Adapter0.5×、0.57×、0.75× |
