Specification | Model | ||||
J-Y16Y | J-Y1YT | J-Y1YA | J-Y1AT | ||
Viewing
head |
Compensation Free Binocular
Head .Inclined at 30 ° |
/ | / | ● | / |
Compensation Free Trinocular
Head .Inclined at 30 ° |
/ | / | / | ● | |
Sliding Binocular Head .Inclined at 45 ° | ● | / | / | / | |
Sliding Trinocular Head .Inclined at45 ° | ● | / | / | ||
Eyepiece | WF10X/ 18mm | ● | ● | / | / |
WF10X/ 22mm | ● | ● | |||
Objective | 195fluorescent objective:4X,10X,40X(S),100X(S) 0il | ● | ● | / | / |
Infinity fluorescent objective:
4X,10X,40X(S),100X (S) 0il |
/ | / | ● | ● | |
20X,60X(S) objective | ○ | ○ | ○ | ○ | |
Stage | Double layers mechanical stage | ● | ● | ● | ● |
Stage size:180mmX 150mm | |||||
Moving range :75mmX 50mm | |||||
Fluoroscope
box |
B 、G Wave band | ● | ● | ● | ● |
U、V Wave band | ○ | ○ | ○ | ○ | |
Focusing |
Coaxial coarse & fine focusing adjustment
with rack and pinion mechanism Fine focusing scale Value 0.002mm |
● | ● | ● | ● |
Condenser |
N. A.1.25 Abbe condenser with
iris diaphragm&filter |
● | ● | ● | ● |
Optional
Accessory |
1.3 or 3.0 Mega pixels CMOS electronic eyepiece | ||||
Photography attachment |
