Optical system | Infinity color corrected optical system |
Viewing
head |
Efficient infinity binocular head, 30°-60° elevation adjustable; 360° rotatable;
interpupillary adjustable distance: 54-75mm; diopter +/-5 adjustable. |
30° inclined binocular head; 360° rotatable; interpupillary adjustable distance: 54-75mm;
diopter +/-5 adjustable. |
|
30° inclined trinocular head, splitting ratio R:T=50:50; 360° rotatable; interpupillary
adjustable distance: 54-75mm; diopter +/-5 adjustable. |
|
30° inclined trinocular head (special for fluorescence), splitting ratio R:T=100:0 or 0:100;
360° rotatable; interpupillary adjustable distance: 54-75mm; diopter +/-5 adjustable. |
|
30° inclined digital binocular head; 360° rotatable; interpupillary adjustable distance:
54-75mm; diopter +/-5 adjustable. |
|
Eyepiece | High eye-point wide field plan eyepiece PL10x22mm, reticle can be assembled. |
High eye-point wide field plan eyepiece PL15x16mm | |
Objective | Infinity plan achromatic objectives (2X,4X,10X,20X,40X,100X) |
Infinity plan phase contrast objectives (10X,20X,40X,100X) | |
Infinity plan semi-achromatic fluorescence objectives (4X,10X,20X,40X,100X) | |
Nosepiece | Revolving quadruple nosepiece/ quintuple nosepiece |
Items Spec and Parameter XSZ-HY1 XSZ-HY2 Order No. Main body / ● ● MS50Xb Eyepiece Plan 10X-18 ●● ●● EP10a Plan 16X-10 ●● ●● EP16a S-plan objective S-plan 4X/0.10 ● ● B-OSPr4 S-plan 10X/0.25 ● ● B-OSPr10 S-plan 40X/0.65 ● ● B-OSPr40a S-plan ...
Items Specification X-OF2 Eyepiece WF 10X-18mm ●● WF 10X-20mm ○○ WF16X-13mm ○○ WF 10X-18 mm (Reticule 0.1mm) ○ Infinity E-Plan Objectives Plan 4X ● Plan 10X ● Plan 20X (S) ○ Plan 40X (S) ● Plan 100X (Oil) (S) ● Main Body / ● Fluorescence Attachment Epi ...
Items Specification X-OF12 X-OF14 Eyepiece WF10×-20 mm ●● ●● WF16×-13 mm ○○ ○○ WF10×-20 mm (Reticule 0.1mm) ○ ○ Infinity Plan Objective 4× ● ● 10× ● ● 20×(S) ● ● 40×(S) ● ● 100×(Oil)(S) ● ● Seidentopf Binocular Head Inclined ...
Parts Specification FY-1B FY-1T Head Binocular head ● / Trinocular head / ● Microscope Main Body Optical System Infinity optical system ● ● Total Magnification 40X-1600X ● ● Eyepiece Plan P10x/φ18mm ● ● Plan P16x/φ14mm ● ● Viewing Head Infinity ...
FY-2 Epi-Fluorescence microscope include fluorescence light and transmitted bright field light system, can be widely used in all kinds of basic theories research and clinical diagnosis, like biology, cytology, histology, oncology, genetics, and immunology. ◆Normal light and ...
