Model | LY2001A | LY2001B |
Eyepiece | Wide field WF10X(µ20mm) | |
Objective | Plan achromatic objectives PL 4X/0.10 | Plan achromatic objectives PL 4X/0.10 |
Plan achromatic objectives PL 10X/0.25 | Plan achromatic objectives PL 10X/0.25 | |
Plan achromatic objectives PL 20X/0.40 | ||
Plan achromatic objectives PL 40X/0.65(Spring) | Plan achromatic objectives PL 40X/0.65(Spring) | |
Plan achromatic objectives PL 100X/1.25(Spring, oil) | Plan achromatic objectives PL 100X/1.25(Spring, oil) | |
Fluorescence objectives FL 25X/0.65 | ||
Fluorescence objectives FL 40X/1.00 (Spring, Glycerin) | ||
Eyepiece tube | Trinocular (Inclination of 30˚) | |
Focus system |
Coaxial coarse/fine focus, with tensional adjustable and up
stop minimum division of fine focusing: 2μm. |
|
Nosepiece |
Quadruple(Backward ball
bearing inner locating) |
Quintuple (Backward ball
bearing inner locating) |
Stage |
Double layer mechanical (Size:160mmX140mm,
Move range: 75mmX50mm) |
|
Abbe condenser | N.A.1.25 Rack & pinion adjustable | |
Filter | Blue filter | |
Frosted filter | ||
Collector | For halogen lamp |
Items Spec and Parameter XSZ-HY1 XSZ-HY2 Order No. Main body / ● ● MS50Xb Eyepiece Plan 10X-18 ●● ●● EP10a Plan 16X-10 ●● ●● EP16a S-plan objective S-plan 4X/0.10 ● ● B-OSPr4 S-plan 10X/0.25 ● ● B-OSPr10 S-plan 40X/0.65 ● ● B-OSPr40a S-plan ...
Items Specification X-OF2 Eyepiece WF 10X-18mm ●● WF 10X-20mm ○○ WF16X-13mm ○○ WF 10X-18 mm (Reticule 0.1mm) ○ Infinity E-Plan Objectives Plan 4X ● Plan 10X ● Plan 20X (S) ○ Plan 40X (S) ● Plan 100X (Oil) (S) ● Main Body / ● Fluorescence Attachment Epi ...
Items Specification X-OF12 X-OF14 Eyepiece WF10×-20 mm ●● ●● WF16×-13 mm ○○ ○○ WF10×-20 mm (Reticule 0.1mm) ○ ○ Infinity Plan Objective 4× ● ● 10× ● ● 20×(S) ● ● 40×(S) ● ● 100×(Oil)(S) ● ● Seidentopf Binocular Head Inclined ...
Parts Specification FY-1B FY-1T Head Binocular head ● / Trinocular head / ● Microscope Main Body Optical System Infinity optical system ● ● Total Magnification 40X-1600X ● ● Eyepiece Plan P10x/φ18mm ● ● Plan P16x/φ14mm ● ● Viewing Head Infinity ...
FY-2 Epi-Fluorescence microscope include fluorescence light and transmitted bright field light system, can be widely used in all kinds of basic theories research and clinical diagnosis, like biology, cytology, histology, oncology, genetics, and immunology. ◆Normal light and ...
