Optical system
Color corrected infinity optical system
Head
Binocular head, 450 inclined, interpupillary distance adjustment
range 54-75mm, one eyepiece tube with ±5 diopter adjustment
Trinocular head, 450 inclined, light splitting ratio:
binocular 100%; binocular 80%/trinocular 20%
Eyepiece
PL10X22mm high eye-point plan eyepiece
PL15X16mm high eye-point plan eyepiece
Objective
Infinity long working distance plan achromatic objective:
LWDPL4X/0.1/WD22 LWDPL10X/0.25WD7.94
LWDPL20X/0.40WD7.66 LWDPL40X/0.60/WD3.71
LWDPL60X/0.70/WD2.50
Infinity long working distance plan phrase contrast objective:
LWDPL10X/0.25WD7.94 LWDPL20X/0.40WD7.66
LWDPL40X/0.60/WD3.71
Nosepiece
Reversed quintuple nosepiece
Focus system
Coaxial focus system, working distance of every circle: 38mm/
coarse focus, 0.2mm/ fine focus,, minimal read 0.002mm/
Stage
160x250mm platform, glass stage/ metal stage, extension plate
Attachable
mechanical stage
Low position coaxial mechanical stage, move range 120x78mm
Specimen holder
Holder for specimen glass (also for φ54mm Tissue culture vessel).
Terasaki holder (also for φ65mm Tissue culture vessel).
Holder for φ35mm Tissue culture vessel
Illuminator
Critical illumination, 90-240V wide voltage, 6V/30W halogen bulb,
center presetting, brightness adjustable. N.A.0.3 condenser,
W.D.72mm, dismountable.
Kohler illumination, 90-240V wide voltage, 6V/30W halogen bulb,
center and focus adjustable, brightness adjustable. N.A.0.3 condenser,
W.D.72mm, dismountable. N.A.0.5 condenser for option, dismountable
Phase
contrast slider
Phase center adjustable slider for XDCD0.3 condenser, with adjusting tools
Phase center presetting slider for XDCD0.3 condenser
Phase center adjustable slider for XDACD0.3 condenser
Phase center adjustable slider for XDACD0.5 condenser
Filter
¢45mm contrast green filter, color temperature change filter,
infrared eliminate filter, rubidium glass filter
Photo attachment
Photo tube(with PK adaptor), 3.2X lens
Video attachment
0.5X/0.67X C mount adaptor
Other optional
functions
Professional fluorescence
(use special fluorescence objective, illuminator and accessory)
