Item | Dimention |
Optical cable model | GYFJH-2B1, Ф7.0mm |
Cable N.W ( Kg/km) | 43.0 |
Cable OD mm | 7.0±0.2 |
Outer jacket material | LSZH |
Outer jacket thickness mm | 1.0±0.1 |
Outer jacket color | black |
Band radius | Static 10D |
Attenuation dB/km | ≦0.4 at 1310nm, ≦ 0.3 at 1550nm |
Short term tensile N | 500 |
Temperature ℃ | -40~+80 |
Fiber SM | 9/125 |
Fiber color | White |
Fiber jacket material | LSZH |
Fiber OD mm | 0.90±0.05 |
Inner jacket color | Orange and blue |
Inner jacket material | LSZH |
Inner jacket OD mm | 1.9±0.1 |
Strength number | Aramid yarn |
Filler color | Black |
Filler material | LSZH |
Filler OD mm | 1.9±0.1 |
Duplex 2.0/3.0mm fiber optical cable is a zip cord fiber optic cable paralleled two 0.9mm simplex cables which is wrapped with steel tape. This cable is mainly used for termination assembling. Description of Duplex Zipcord Tight Buffered Armored Fiber Optic Cable GJSFJV 0.9mm ...
Item Unit Dimentions Optic fiber mm 0.60±0.1 Spiral armored layer mm 1.20±0.10 Aramid yarn decitex 1100 Outer jacket mm 2.0±0.1 Applications l As the connector among optical equipment and instrument; l Used in communications in data center, during ODF with armored ...
