Cast Iron Ore Mining Cart Wheel Set

Introduction of Cast Iron Ore Cart Mining Wheel Set

We are manufacturer of railway mine wagon wheels, for example: 600 gauge mine car wheel, 600 gauge mine cart wheel, material of rail cart wheel is 350 steel and cast iron, shaft thick have 50 mm, 55 mm, 60 mm, 75 mm diameter gauge, 600 round of 200, 240, 300, and 350 are all in stock, gauge 762, 900, 1435 to need to make to order.

1. Material: cast steel or cast iron;
2. Constitute: two wheels, one axle, four bearings, and other parts;

3. Loading capacity: 1-25 tons, each one is OK;

4. Wheel sets gauge: 600mm, 762mm, 900mm, and etc;

5. The type of the wheels: hollow wheel sets and solid wheel sets;

6. The diameter of the wheels: 300mm, 350mm, 400mm, 450mm;

7. The material of the axle: 45# steel, or Q235;

8. The quantity of each wheel\'s bearing: two;

9. The material of the bearing: LYC32212, conical roller bearing, deep groove ball bearing;

10. Weight: 70kg.

Parameter of Cast Iron Ore Mining Cart Wheel Set

Model	Mine Car Weight kg	Track mm	Wheel Diameter	Max Axle Distance of wheels	Min distance of covers	Axle diameter
ZBL600/300	≤2400	600	300	808	510	60
ZBL762/300	762	970	672
ZBL900/300	900	1108	810
ZBL600/350	≤6700	600	350	850	490	80
ZBL762/350	762	1012	652
ZBL900/350	900	1150	790
ZBL600/400	≤9000	600	400	870	476	95
ZBL762/400	762	1032	638
ZBL900/400	900	1170	776
