SWM305P156 SPECIFICATION:
ELECTRICAL DATA @ STC
Peak Power Watts Pmax(WP): 305
Power Output Tolerance Pmax(%):+3
Maximum Power Voltage Vmp(V):36.8
Maximum Power Current IMPP(A):8.30
Open Circuit Voltage Voc(V):45.6
Short Circuit Current Isc(A);8.91
Module Efficiencyηm(%):15.7
Values at Standard Test Conditions STC(Air Mass AM1.5,Irradiance 1000W/㎡。Cell Temperature 25℃)
ELECTRICAL DATA @NOCT
Maximum Power Pmax(Wp): 225
Maximum Power Voltage Voc(V):34.0
Maximum Power Current Impp(A):6.62
Open Circuit Voltage Voc(V):42.4
Short Circuit Current Isc(A):7.21
NOCT: Irradiance at 800W/㎡,Ambient Temperature 20℃,Wind Speed 1m/s
MECHNICAL DATA
Solar Cells: Mono-crystalline 156*156mm (6 in)
Cell Orientation: 70 cells (7*10)
Module 1956*992*40mm (62.2*41.89*1.57 in)
Dimensions
Weight: 22kg (48.5 Ib)
Glass: High transparency solar glass 4.0mm (0.16 in)
Frame: Anodized aluminum alloy
J-Box: IP 65 rated
Cables: Photovoltaic technology cable 4.0mm²(0.0062 in²)
Connector: Original MC4 PLUS
TEMPERATURE RATINGS
Nominal Operating Cell Temperature(NOCT): 45℃(±2℃)
Temperature Coefficient of Pmax: -0.43%/℃
Temperature Coefficient of Voc: -0.32%/℃
Temperature Coefficient of Isc: 0.04%/℃
MAXIMUM RATINGS
Operational Temperature: -40℃~+85℃ 10 Year Product
Maximum System Voltage: 1500V DC(IEC)/ Workmanship Warranty
1000V DC(UL) 25 Year Linear Power
Max Series Fuse Rating: 15A Warranty
