315w poly solar panel

SWM315P156 SPECIFICATION:

ELECTRICAL DATA @ STC

Peak Power Watts Pmax(WP):  315

Power Output Tolerance Pmax(%):+3

Maximum Power Voltage Vmp(V):37.2

Maximum Power Current IMPP(A):8.48

Open Circuit Voltage Voc(V):46.2

Short Circuit Current Isc(A)；9.01

Module Efficiencyηm(%)：15.2

Values at Standard Test Conditions STC(Air Mass AM1.5,Irradiance 1000W/㎡。Cell Temperature 25℃)

ELECTRICAL DATA @NOCT

Maximum Power Pmax(Wp): 233

Maximum Power Voltage Voc(V):34.7

Maximum Power Current Impp(A):6.71

Open Circuit Voltage Voc(V):42.8

Short Circuit Current Isc(A):7.28

NOCT: Irradiance at 800W/㎡，Ambient Temperature 20℃，Wind Speed 1m/s

MECHNICAL DATA

Solar Cells:  Mono-crystalline 156*156mm (6 in)

Cell Orientation:  70 cells (7*10)

Module         1956*992*40mm (62.2*41.89*1.57 in)

Dimensions

Weight:  22kg (48.5 Ib)

Glass:  High transparency solar glass 4.0mm (0.16 in)

Frame:  Anodized aluminum alloy

J-Box:  IP 65 rated

Cables:  Photovoltaic technology cable 4.0mm²(0.0062 in²)

Connector:  Original MC4 PLUS

TEMPERATURE RATINGS

Nominal Operating Cell Temperature(NOCT):  45℃（±2℃）

Temperature Coefficient of Pmax:  -0.43%/℃

Temperature Coefficient of Voc:   -0.32%/℃

Temperature Coefficient of Isc:    0.04%/℃

MAXIMUM RATINGS

Operational Temperature:  -40℃~+85℃            10 Year Product

Maximum System Voltage: 1500V DC(IEC)/           Workmanship Warranty

                      1000V DC(UL)            25 Year Linear Power

Max Series Fuse Rating:   15A                     Warranty
