We supply knitted wire mesh washers to UK, Germany, India and other countries.
Open cell knitted titanium mesh washer - Foam Lance Mesh filter
Diameter 20mm, thickness 2.5mm
Flat-type mesh surface and pressed into a corrugated bellows-type network surface
Width of the corrugations and the depth varies to meet specific uses.
Compressed Knitted Wire Mesh Grounding Washers with the following dimensions, for Germany
Part name: DG-Ring
Material: 1.4301 (X5CrNi18-10) / AISI 304 /
Wire thickness: 0.16 mm
Outer diameter: 19.5 mm +/-0,3 mm
Inner diameter: 11,3 mm +0,4/-0 mm
Heigth: 5,5 mm +/-0,3 mm
Density: 1,8g/cm³
Material: SS304 Knitted mesh
Outer diameter 15 mm
Inner diameter 6 mm
Thickness 3 mm
Copper Knitted Wire Mesh is one of the main components of wire mesh demister and other separation engineering filter element parts for Gas Liquid Filtration. Flat copper mesh demisters serve well in removing the particle mixture in foam, liquid and air, by way of distillating, ...
Yingdu supplies a wide range of knitted wire meshes in galvanized, ss, copper, nickel Knitted wire mesh is a filter fabric made by interweaving strands of wire, typically stainless steel or copper, in a pattern to create a mesh surface with fine openings. Forms of Knitted Mesh: ...
COMPRESSED KNITTED STAINLESS STEEL WIRE MESH Compressed knitted wire mesh is used mainly for cylinder filters and strainers. Compressed knit mesh features: High strength and overall rigidity; Good air permeability; Excellent filtering accuracy; Good filter resistance, ...
KNIT MESH TAPES As a supplier of knitted wire mesh tape for EMI/RFI shielding, we export knit wire mesh in tape form for Europe and other countries. Knit Wire Mesh Tape - Alloy Mesh Tape Material in 300 feet length. Material Type: Knit Wire Mesh Tape Tape form: Tin / copper ...
KNITTED WIRE MESH SLEEVES We supply knitted mesh sleeves and knit mesh for sleeves. Materials applied for mesh sleeving: Stainless steel Galvanized steel Nickel alloy ( monel, inconel ) Knit Wire Mesh Sleeves ( S.S.) Knitted wire mesh sleeves Dimensions: Inner diameter: 1.5\" ...
