FEATURES:
A.The machine is suitable for filling capsules of all sizes with powder, granules and pellets.
B.Automatic declutching of loader when loading rings are full which minimizes operator attention and ensures maximum production.
C.Choice of four auger speed with variable speed of filling table provides flexibility to achieve accurate weight.
D.Auto drug hopper in feed mechanism, reduces weight variation and improves productivity.
E.Simple structure and low malfunction, easy to maintain and clean.
F.Quality and precision manufacturing meets the requirement of CGMP.
G.Both, PLC controlled panel or digital controlled panel, with auto capsule loader closing system available to meet customers requirement.
Technical Specifications:
Output | 25,000 to 40,000 capsules/hour. |
Electrical | Loader Drive: 0.25 HP, 380/440 Volts, 3Ph, 50 Cycles |
Auger Drive | 1.5 HP, 380/440 Volts, 3Ph, 50 Cycles |
Filling Table Drive | 0.5 HP, 380/440 Volts, 3Ph, 50 Cycles |
Vacuum Drive | 3 HP, 380/440 Volts, 3Ph, 50 Cycles |
Compressed Air | 200 Ltr/min. (8cfm) at 100 PSI. |
Vacuum | 500mm (20") of Hg. At 1000 ltr./min. (30cfm) |
It is an intermittent full automatic capsule filling machine with multiple tamping stations, precise design and stable performance. Following processes are completed: capsule feeding, capsule separating, powderfilling, defective capsule rejecting, capsule closing, finished ...
Semi automatic strapping machine is suitable for cartons, calcium-plastic cases, books, soft and hard packages as well as all kinds of articles in square, cylinder or annulations. The machine with high table is suitable for general objects, while that with table in middle height ...
The hard capsule filling machine helps to increase job productivity by simplifying the five-point leveling mechanism, making it easier to clean up scattered powder. The front and rear dislocation module hole arrangement method improve powder filling accuracy, resulting in a ...
The whole pill capsule filling machine adopts modular design, positioning pin positioning, disassembly and installation more quickly. The transmission mechanism has been optimized design so that the overall pill capsules machine is more stable, more accurate action, less ...
This automatic encapsulation machine for sale , which is also called capsule making machine, is designed scientifically and logically with a frame structure. The hard capsule automatic encapsulation machine pharmaceutical drops the location of transmission part gravity to make ...
PLC control and electronic components choose the international famous brand, such as Siemens, Schneider, Omron, and so on, nice, safely, reliably. Touch screen and PLC control, scientifically, advanced, efficient. Advanced SEW motor and NASH vacuum pump guarantee the stability ...
Smart Pack semi-automaticstrapping machine The Smart Pack semi-automatic strapping machine is easy to operate, with simple and intuitive controls. The package is placed on the machine\'s table or conveyor, and thestrap is manually fed through the machine\'s dispenser and ...
The Low Table Top Strapping Machine can be used to strap books, soft and hard packages, cartons, calcium-plastic cases, square, cylinder, and annulated articles of all kinds. Packages that are extremely heavy or very large can be handled by the machine with a very low table. ...
With our endeavor to offer the next generation technology in offering the latest Auger filler, we introduce Automatic Double head Auger powder Filler which is available for sales to the various industries at reasonable price. The machine can deliver production speed of 60 ...
The medicine capsule filling machine equipment of LIAONING TIANYI is a new model designed to meet the needs of mass production on the basis of the original popular series. As a professional capsule filling machine manufacturer, LIAONING TIANYI has made further improvements to ...
