Wood crusher is ideal equipment for producing various types of wood products.It can crush tree branches and stems with the diameter of 70mm-250mm and moisture content of above 30%.
Wood Crusher Introduction Wood crusher is ideal equipment for producing various types of wood products. Wood pellets or biomass briquettes production line also needs crushing equipment. Wood crusher is specially designed to crush branches, tree roots,slab scraps and so on for further production.It occupies little room which makes it quite a popularity in small size biomass fuel plants. | Our Wood Crusher Features 1. Reasonable design, improves crushing efficiency by 50% compared to traditional type. 2. Attractive appearance, high output of 400-2000kg/h. 3. One motor drives crushing, energy saving and low cost. 4. Crushed materials are fit to process pellets or briquettes. |
What Materials Can be Crushed Raw materials can be processed by wood crusher are various, but there is also a standard about the size. Generally speaking, it can crush tree branches and stems with the diameter of 70mm-250mm. Many fiber stalk like bamboo, couch grass, corn and Sorghum stalks are also common wood pellets materials. The crushed materials are particles and with diameter of about 3-5mm and can be directly for pelletizing or briquetting. How Does a Wood Crusher Work Wood crusher integrates cutting and crushing. Blades cutting and high speed air impacting works together to make it a good crushing machine. During blade cutting, rotator creates high speed air and spins with blade cutting direction. Raw materials speed up in the air and impact repeatedly to crushed them completely. Wood crusher mainly consists of cutting device,crushing equipment and draught fan. Small body and good flexibility. |
Wood Crusher Maintenance
☆ The bearings should be injected oil after the machine working for three to four hours.
☆ Adjust the tightness of v belt after using for a period, lower 6—10mm is suitable.
☆ Clean and examine carefully of every part of the machine, if there is any malfunction, repair in time.
Wood Crusher Technical Data
Model | Capacity | Weight | Inlet Size | Dimension | Power |
AMS—MFS600 | 0.6—0.8 | 550 kg | 200x200 mm | 1.4x0.8x0.8 m | 11—15 |
AMS—MFS700 | 0.8—1.0 | 800 kg | 200x260 mm | 1.6x0.8x1.0 m | 15—22 |
AMS—MFS800 | 1.2—1.7 | 1200 kg | 250x300 mm | 1.6x1.2x1.3 m | 15—22 |
AMS—MFS900 | 2.5—3.2 | 2300 kg | 300x400 mm | 2.6x1.6x1.6 m | 15—22 |
AMS—MFS1000 | 3.5—4.5 | 2800 kg | 340x450 mm | 2.8x1.8x1.8 m | 45--55 |
AMS—MFS1200 | 4.5—5.5 | 3300 kg | 380x500 mm | 2.8x1.8x1.8 m | 55--75 |
