Wet Type Fish Feed Machine Introduction
The wet type fish feed extruder is equipped with a boiler which can continuously providing hot steam. It can produce all kinds of floating or sinking aqua feed for fish, eel, shrimp, crab, loach, bullfrog, etc, and can produce many kinds of pet feeds for cat, dog, and etc. The pellet size can be from 0.9-15mm to feed different size fishes. High capacity and top quality products, our fish feed extruder is a preferred choice for medium or large size feed processing factory and aquaculture farm.
Advantages of Fish Feed Extruder
◆ Feeding evenly and constantly: Flat-bottomed scraper mechanism and feeder controlled by transducer make sure that the materials can be fed evenly and constantly.
◆ High efficiency and low power consumption: With conditioner, the steam and water can be directly injected into the extruding chamber through special mechanism, thus the quality and quantity of products can be improved greatly with lower power consumption.
◆ Cutting quickly and accurately: Removable cutting mechanism use knives with good elasticity, which attach to the die plate tenderly and can be regulated in six directions, can be operated quickly
and accurately.
◆ Wide application: Variably configurations of screw bolts can match the producing demands for
different formulas and raw materials.
◆ Longer service life: Screw bolts and dies are processed through vacuum quench treatment, also be processed with high processing precision and have a long using longevity.
◆ Easy operation: All the operating parts like steam valves, etc, adopt the humanization design, in order to facilitate actual operations.
Superiorities of Wet Type Fish Feed Extruder Conditioner
▶ Screw sleeve adopts jacketed construction, which can be injected in with hot steam or cooling water, thus the extruding temperature can be controlled effectively.
▶ The conditioner can make the materials have fully gelatinization of starch by a combination of hot steam and mechanical shear/mixing. The materials may remain in the conditioner for a time over 180s.
Cutter and Moulds
| Conditoner |
you can try for fish to get through more products
The belt-type ring dies feed pellet machine is a large-scale feed pellet machine, which is used to make corn stalks, bean stalks, flower seedlings, sweet potato wine, clover, rape straw, etc. into cattle feed, pig feed, cattle feed, sheep feed, rabbits feed, chickens feed, ...
Our wet-type fish feed pellet production line is the complete procedure of a fish feed-producing plant, which includes a fish feed-making machine, fish feed crusher, fish feed mixer, fish feed dryer, and other equipment. It is used to produce a variety of materials into ...
Herm machinery high-quality fish feed pellet mill plant can produce various fish feed pellets, including grass carp feed, herring feed, carp feed, trout feed, tilapia feed, salmon feed, catfish feed, etc. The raw materials of the complete fish food plant production line include ...
Model DGP60-B Capacity (t/h) 0.10-0.12 Main power (kW) 15 Feeding power(kW) 0.4 Spiral diameter (mm) Φ60 Cutting power 0.4 fish feed extruder’s parameter ...
Model DGP70-B Capacity (t/h) 0.18-0.20 Main power (kW) 18.5 Feeding power(kW) 0.4 Spiral diameter (mm) φ70 Cutting power 0.4 ...
Model DGP70 Capacity 180-250kg/h Main power 18.5kw Cutter power 0.4kw Feed supply power 0.4kw Screw Diameter 70mm Size 1600*1400*1450mm Weight 600kg ...
Model DGP70-B Capacity (t/h) 0.18-0.20 Main power (kW) 18.5 Feeding power(kW) 0.4 Spiral diameter (mm) φ70 Cutting power 0.4 ...
Model DGP80-B Capacity (t/h) 0.2-0.3 Main power (kW) 22 Feeding power(kW) 0.6 Spiral diameter (mm) φ80 Cutting power(kW) 0.6 Size(mm) 1800*1450*1300 Weight(kg) 695 fish food pellet mill’s parameter ...
