Parameter
All of these models can be customized according to customer requirements.
NO. | Description | Parameter |
1 | X,Y,Z working area | 1300*900mm(1400*1000mm, 1600*1000mm) |
2 | Driving system | Stepper |
3 | Laser power | RECI Laser 60w, 80w, 100w, 130w |
4 | Laser type | Sealed co2 laser tube |
5 | Working platform | T- Blade worktable(honeycomb table for option) |
6 | Watercooling form | Water-cooling chiller with air compressor |
7 | Interface | USB |
8 | Cutting speed | 0-5000mm/min |
9 | Working power | AC110v - 220v, 50hz -60hz |
10 | Graphic format supported |
*.plt, *.dst, *.dxf, *.bmp, *.dwg,*.al, *.las |
11 | Recommended Spare Parts | Laser Tube and Lens |
12 | Running Environment Temperature | 0 degree - 45 degree |
13 | Software supported | CorelDraw, Photoshop, AutoCAD |
14 | Guarantee | One year from the date of commission |
15 | Optional Accessories |
①Rotary system
②Laser tube and Lens ③Motorized up and down table |
Application
1. Wood carving/ cutting, bamboo, window processing, cabinets doors and panels, computer table and
Plate furniture auxiliary processing, jade, marble, organic glass, crystal, plastic, garments, paper, leather,
rubber, ceramic, glass and other nonmetal materials.
2. Advertising industry processing: Acrylic cutting, Advertising signs, logo production, forming system
module, arts and crafts, shoes, toys, garments, a variety of the production of advertising decorative products.
3. Mold material industry: the wooden, as well as artificial marble, sand, plastic sheeting, PVC pipe, and
other non-metallic mold.
Youtube links:
NO.1 jinan APEXTECH CNC 1390 laser machine cutting acrylic material
NO.2 Asian products jinan apexcnctech 1390 on clothe with 2 heads cutting
NO.3 apextech cnc laser cutting machine for cutting MDF board
