Atmel AT91SAM9X25 single Board, two Ethernet, two CAN, SPI, IIC
Product Quick Detail
- Packaging
- 0.5 KG
- Delivery
- 2 Days
Specifications
http://armdevs.com/NET-SAM9X25.html
NET-SAM9X25 Features
Working Temperature: -40 to +85 Celsius
Base on AT91SAM9X25, with 128MB DDR2 and 256MB Flash
two Ethernet, Two CAN, SoftWare Modem
Zigbee interface, USB Host/Device
Expand All the interface for CM-SAM9X25
Support Linux 2.6.39 system
HardWare
CPU Board:CM-SAM9X25
Dimensions: 57*39mm, 8 layer
Working Temperature: -40 to +85 Celsius
Atmel AT91SAM9X25 ARM926EJ-S Core Microprocessor
128MByte DDR2 RAM, 256MByte Flash, 4kbit EEPROM
Two 100Pin connector extend more function
Expand two Ethernet, Two CAN Bus, Serial port
Software Modem,USB Host/Device, SDIO, TWI, SPI
Mechanical Parameters
Dimensions:115*74mm
Power Input Voltage: 12V
Temperature Range: -40 ℃ ~ 85 ℃
Humidity Range: 20% ~ 90%
Data Transfer Interface
Serial port
DEBUG: One 3-wire TTL Debug serial port(provide TTL_RS232 module)
COM0: One 5-wire TTL serial port, Support extend RS232/RS485 Module
Ethernet: Two 10/100Mbps Ethernet port (RJ45)
USB port:
Two High-speed USB 2.0 Host port, 480Mbps
One High-speed USB 2.0 Device port, 480Mbps
TF card slot: One TF card interface(Hot plug-and-play)
Zigbee interface
Soft Modem interface
Expansion Interface
J1:3 x Uart, 1 x SPI, 4 x GPIO
J3: 6 x AD, 4 x PWM, 1 x Uart
J4: 6 x IO, 1 x USB, 1 Soft Modem
J5: JTAG, 2 x SPI, 1 x SSC, 1 x TWI
Input Interface
1 LED: 1 x Power LED
2 Button: 1 x Reset KEY, 1 User Key
SoftWare
Support Linux 2.6.39 System
UBI Filesystem
CAN bus driver
Ethernet Driver, Telnet, TCP/IP
USB Host, Soft Modem
Applications
Industrial control
Field Communication
Email: market@armdevs.com
For more details,please refer to:
http://armdevs.com/NET-SAM9X25.html
