2000Lbs Electric Winch
Product Quick Detail
- Packaging
- carton box, plastic bags, wooden cases or as your requirement
- Delivery
- 5-10 days after your payment
Specifications
Product Introduction chinacoal05
2000 Lbs Electric Winch Features:
1.Brake Assembly
Mechanical brake design , makes vehicle safety on the steep
2. Waterproof Design
Level six water-proof design expands the use of situation and long life time.
3. Low -temperature Grease
The gear box using low-temperature grease (-40 ) so that the gear can still work freely in extreme cold weather.
4. Big-power and endurable motor.
With high-performance magnet ,silver and copper commutator , high-density carbon brush , endurable 130 oil painting on wire.
5. High-quality synthetic rope instead of wire rope , make the winch light weight
Main Parameter
| Single line rated pull | 2000lb(907kg) |
| Motor | 0.7KW/0.9hp(12V) permanent magnet |
| Gear train | 1 Stage Planetary |
| Gear ratio | 153:1 |
| Cable | 5/32" x 50'(4.0mmx15.2m) |
| Drum size | 1.24” x 2.88”(31.5 x 73mm) |
| Dimensions | L x W x H (285 x 105 x 105mm) |
| Mounting bolt pattern | 3.13”(79.5mm) |
| Weight | G/W:9.0KGS N/W:7.5KGS |
- Country: China (Mainland)
- Business Type: trading company
- Market:
- Founded Year:1994
- Address:No.69 Huoju Road, New & High Zone,Jining City,Shandong Province,China
- Contact:Elena Sun
