20T Zinc injection machine
Product sourcing details
- Packaging
- wooden case
Supplier: KYLT industrail limited
Purchasing information
- Lead time
- 65 Days
Please confirm with the supplier: Model / reference, Key specifications / compatibility, Minimum order, Samples, Export markets, Supply capacity.
Specifications
Tonnage:20T | Die locking force:200KN | Tie-bars dia.:40MM |
Die stroke: 130MM | Tie bars space:232*278MM | Mold thickness:150-220MM |
Max.injection force: 21KN | Ejection force:13KN | Flow rate of oil pump:31L/min |
Working oil pressure:6-7Mpa | Output of pump motor:5.5/6Kw/P | Melting pot capacity(Zn.):120KG |
Accumulator capacity:10L | Oil tank capacity:200L | Input of furnace heating:9KW |
Machine weight : 2.0T | Machine size: 3000*980*1700MM |
|
KYLT 20T Zinc injection machine,also named, 20T zinc(Zn.) hot chamber casting machine, zinc metal injection machine,or metal casting machine, zipper casting /injection machine.
Other we have 12T,20T,22T(PLC),30T hot chamber die casting machines for our client to choose.Those machines can be used to cast, zinc(Zn. or Zamark), lead(Pb.), Tin alloy etc low melting point materials.
Main used to cast: zinc auto parts, zinc zipper head and puller,zinc spoon, coin, lable, logo, jewelry, battery lead(Pb.) bushing and terminal etc.
