30T Zinc / Lead injection machine

Tonnage:30T

Die locking force:300KN

Tie-bars dia.:45MM

Die stroke: 150MM

Tie bars space:270*320MM

Mold thickness:160-310MM

Max.injection force: 36KN

Ejection force:20KN

Flow rate of oil pump:41L/min

Working oil pressure:7-8Mpa

Output of pump motor:5.5/6Kw/P

Melting pot capacity(Zn.):160KG

Accumulator capacity:16L

Oil tank capacity:200L

Input of furnace heating:12KW

Machine weight : 2.5T

Machine size: 3000*1100*1900MM

KYLT 30T Zinc / Lead injection machine,also named, zinc(Zn.) lead (Pb.) hot chamber casting machine, Pb metal injection machine,or lead metal casting machine.
Other we have 12T,20T,22T(PLC) hot chamber die casting machines for our client to choose.Those machines can be used to cast, zinc(Zn. or Zamark), lead(Pb.), Tin alloy etc low melting point materials.
Main used to cast: zinc auto parts, zinc zipper head and puller,zinc spoon, coin, lable, logo, jewelry, battery lead(Pb.) bushing and terminal etc.
