Application of GF Series Dry Air Generator:
Technical Features of GF Series Dry Air Generator :
Item |
Parameter |
Model
Unit |
GF-50 |
GF-100 |
GF-150 |
GF-200 |
Technical Parameter | Flow | M³/h | 50 | 100 | 150 | 200 |
Working Pressure | Mpa | 0.6~0.8 | ||||
Pressure Drop | Mpa | 0.05 | ||||
Noise | dB(A) | 70 | ||||
Working Power | KW | 380V-50Hz 3 Phase 4 Wire | ||||
Total Power | KW | 12 | 19 | 22 | 26 | |
Size |
Length | cm | 215 | 215 | 230 | 230 |
Width | cm | 155 | 155 | 165 | 165 | |
Height | cm | 230 | 230 | 230 | 230 | |
Diameter | DN | 32 | 40 | 50 | 50 | |
Weight | Kg | 900 | 980 | 1030 | 1050 | |
After Treatment Index | Discharge Pressure | Mpa | 0.02~0.03 | |||
Dew Point | °C | -50°C ~ -70°C | ||||
Particle | um | 0.01 | ||||
Oil content in air outlet | ppm | 0.01 |
