Techinical parameters
Engine Mode:ZS152FMI-5
Engine Name:ZY125
Engine Type:Single cylinder,4-stroke,water-cooling, camshaft upward
Displacement(ml):125
Dimension(mm×mm×mm):350×320×430
Net Weight(kg):28
Max.Power(kw/r/min):7.2(1±10%)/7500(1±5%)
Max.Torque (N.m/r/min):9.2(1±10%)/6000(1±5%)
Compression Ratio:9.2:1
Bore and Stroke(mm×mm):52.4×57.8
Lubrication method:Pressure and Splash
Min.Fuel Consumption(g/Kw.h):≤367
Starting method:Electric
Clutch method:Manual Wet Multi-Plate
Gearshift Method:Constant mesh, two stage transmission ,5-speed Gearshift
Seller:Chongqing Zongshen Engine Manufacture Co., Ltd. contact:zhangxz@zsengine.com 1,100cc/110cc for Rickshaw or Motorcycle 2,In CBU 3,CKD is also optional 4,Self-start is optional 5,110cc is optional 6\'Naked engine Chongqing Zongshen Power Machinery Co., Ltd., the core ...
