HOWO MOBILE WORKSHOP QDZ5190YX 4X4

MAIN TECHNICAL DATA

Complete
Vehicle

Tare Weight

11,950 Kg

Loading Capacity

3,050 Kg

Drive Type

4X4

Tyres

6+ 1; 12R22.5 STEEL TYRE,

Max. Speed

75 KPH

Max. Gradeability

40%

Minimum Ground Clearance

298 mm

Overall Dimensions

7770 x 2520 x 3760 mm

Wheel Base

4300 mm

Fuel Tank Capacity

400L

Engine

WD615.62; 6 Cylinder in Line, Water Cooling Diesel Engine, Turbo Charged with Intercooler; 266hp/2200rpm;

Gearbox

FULLER RT-11509C; 9 Forwards & 1 Reverse

Colour

Army green

Equipments for Mobile Workshop QDZ5190YX

Item

Description

Technical Data

Measurement

Weight

Qty.

1

Power Set
(Generator)

Model: 40GF74-4

2030x650x1255(mm)

1030kg

1

Rated Power: 40KW

Rated Voltage: 400/230V

Rated Frequency: 50Hz

Rated Current: 72.2A

Output: 3-phase, 4-line

Diesel Engine: R4100ZD

Generator Model: TZH-40

2

Welding Set

Model: ZX5-250B

406x530x840(mm)

160kg

1

Voltage: 380V

Phase: 3

Frequency: 50/60Hz

Initial Current: 29.6A

Range: 25-250A

Input: 19.2KVA

Working Ambient: -10--+40oC

3

Air Compressor

Model: AW3608

1180x410x850(mm)

130kg

1

Voltage: 380V

Frequency: 50Hz

Power: 3KW

Pressure: 0.7MPa

Capacity: 0.36M3/mm

4

Drilling Machine

Model: ZQJ4119AD

760x490x260(mm)

57kg

1

Bore Range: 3--16mm

Power: 700W
