Mini handkerchief machine

Introduction

Feature and function

1.Put a roll in the form of flat belt push, equipped with stepless speed regulating device, rolling tension can be adjusted.

2.Embossed steel roller on wool roller (according to customer requirements using other material embossing roll).

3.Folding adopt vacuum adsorption form.

4.Each part adopt synchronous belt.

5. Can produce different specifications of the models according to the requirement, can increase 1-4 color flexo printing device.

Technical parameters

grammage	13-20g/m
Stable production speed	500-600pcs/min
Unfold size	W:140-210mm
Folding dimensions	（68-115）×（50-83）mm
The diameter of Jumbo Roll paper	≤1200mm
A roll of paper specification	13-16g/m2(3ply) 17-22g/m2(2ply)
Installed power	1.5KW
The vacuum fan power	3.0KW
Voltage	220/380 V
Equipment weight	≈ 1.2T

Quanzhou Taifeng Machine Technical Co., Ltd was founded in 2013 as manufacturer in Quanzhou China. The factory is located in Fujian province in China and covers land of 17,000 square meters, of which 10,000 square meters is for workshop, warehouse and office building etc. After many years’development, Taifeng has been keeping development, and now is booming the business worldwide to Japan, Spain, India, Egypt, Mauritius, Indonesia, Colombia, South Africa, etc.
