D9 Series DC Leakage Current Tansducer / Tansmitter
Product sourcing details
- FOB Price
- USD $25.00 / Piece
- Place of Origin
- China (Mainland)
- Packaging
- carton
Supplier: SAIS CO.,LTD.
Purchasing information
- Minimum order
- 1
- Lead time
- 15 Days
Please confirm with the supplier: Model / reference, Key specifications / compatibility, Samples, Export markets, Supply capacity.
Specifications
Using Magnetic modulation acquisition technology
Straight-through current input mode, high isolation ability
High sensitive, high performance-price ratio
Linear measuring range: 0 - 120% of nominal input
Isolation: >3kV DC 1min
Overload: 500% of nominal input, 5 seconds.
Mean Time Between Failure(MTBF): >30000 hours
Wide temperature zone product request is available
Straight-through current input mode, high isolation ability
High sensitive, high performance-price ratio
Linear measuring range: 0 - 120% of nominal input
Isolation: >3kV DC 1min
Overload: 500% of nominal input, 5 seconds.
Mean Time Between Failure(MTBF): >30000 hours
Wide temperature zone product request is available
| Model | Accuracy | Input | Output Unit | Output | Responding Time | Static Power Consumption | Power Supply | Working Temperature (º C) |
| CDLC-Z2D92-XXA/ | 1.0 | Φ 20 through hole DC leakage current: 20mA-100mA | VZ | 5V | 100ms | 300mW | ± 15V DC | -25 - 70 |
| CDLC-Z2D91-XXA/ | 1.0 | VZ | 5V | 100ms | 300mW | 24V DC | -25 - 70 | |
| CDLC-Z2D95-XXA/ | 1.0 | VZ | 5V | 100ms | 250mW | 12V DC | -25 - 70 | |
| BDLC-Z4aD92-XXA/ | 1.0 | IZ | 4-20 mA | 300ms | 350mW | ± 15V DC | -25 - 70 | |
| BDLC-Z4aD91-XXA/ | 1.0 | IZ | 4-20 mA | 300ms | 400mW | 24V DC | -25 - 70 | |
| BDLC-Z4aD95-XXA/ | 1.0 | IZ | 4-20 mA | 300ms | 300mW | 12V DC | -25 - 70 |
