The rated output power of TP10DB converters is 10W,the outline dimensions is \"25.4*25.4*11.2\",
4:1 wide input voltage range,the voltage range is 9V-36V,18V-72V .The accuracy of the converter can reach ±1%,it can be widely used in telecommunications,railway transportation, instrument and etc.

10W output power    Long-term short-circuit protection, Auto recovery       High switching frequency , High output density

Metal shell package ( full shield)     With remote control and output adjustment function      RoHS compliant

SELECTION GUIDE

Part Number   Input Voltage   Output  Efficiency

(Typ)

%      Ripple and noise（mV）

Voltage （VDC)    Voltage（VDC)    Current（A）

Rated      Range values

TP10DB24S05W     24(4:1) 9-36    5.05    2.0     84      100

TP10DB24S24W      24(4:1) 9-36    24      0.42    86      100

TP10DB48S05W      48(4:1) 18-72   5.05    2.0     84      100

parameter conditions      Min     Typ     Max     Units

Voltage accuracy                                ±1

Adjustment rate                            ±0.2

Load effect                              ±0.5

Dynamic Response 50~75% Load

±4%Vo Overshoot

Dynamic Response        50~25% Load

400μS Recovery Time

Temperature drift coefficient                       ±0.02

Ripple & Noise      20MHz Bandwidth                 100
