Universal input voltage range | Both for AC and DC input voltage | Low Ripple &Noise |
High efficiency, high power density, miniature dimensions | Low power consumption≤30mW | Overheat protection ,Over current protection |
International standard Footprint&Pinouts | Industrial product design | Operating temperature : -40℃to 70℃ |
SELECTION GUIDE | |||||
Part Number | Input Voltage | Output |
Efficiency (Typ. )
% |
||
Voltage(VAC) | Voltage(VDC) | Current(A) | |||
Rated | Range values | ||||
TP03AL220S03LSW | 220(4:1) | 85-265 | 3.3 | 0.60 | 63 |
TP03AL220S05LSW | 220(4:1) | 85-265 | 5 | 0.60 | 68 |
TP03AL220S09LSW | 220(4:1) | 85-265 | 9 | 0.33 | 72 |
TP03AL220S12LSW | 220(4:1) | 85-265 | 12 | 0.25 | 74 |
TP03AL220S15LSW | 220(4:1) | 85-265 | 15 | 0.20 | 76 |
TP03AL220S24LSW | 220(4:1) | 85-265 | 24 | 0.125 | 80 |
All specifications typical at TA=25°C, nominal input voltage and rated output current unless otherwise specified. |
