Model |
exradius OD mm(inch) |
inradius ID mm(inch) |
Stroke mm(inch) |
Max. tensile load in down hole MN |
Sealing pressure MPa |
Max. working temperature ℃ |
Connection API |
Overall length mm(inch) |
YJS46 | 121(4 3/4) | 38(1 1/2)) | 224(8 3/4) | 0.9 | 20 | 120 | NC38 | 3275(129) |
YJS62 | 159(6 1/4) |
57.2 (2 1/4) |
329(13) | 1.5 | 20 | 120 | NC50 | 4380(172) |
YJS64 | 165(6 1/2) |
57.2 (2 1/4) |
329(13) | 1.5 | 20 | 120 | NC50 | 4380(172) |
YJS70 | 178(7) |
60 (2 5/16) |
336 (13 1/4) |
1.8 | 20 | 120 | 5 1/2FH | 3740(147) |
YJS76 |
197 (7 3/4) |
76.2(3) |
333 (13 1/8) |
2.1 | 20 | 120 | 6 5/8REG | 4238(167) |
YJS80 | 203(8) | 76.2(3) |
333 (13 1/8) |
2.2 | 20 | 120 | 6 5/8REG | 4238(167 |
1. Main Technical Parameters: 2. Product Description: Hydraulic jar (up / down) designed to use accelerator and flow sub from a coiled tubing short heavy string. The jar delay device let the energy stored in the stretched and elongated strong accelerator, when the energy ...
Hydraulic winch is a lifting equipment driven and braked by hydraulic. It has the advantages of compact structure, light weight, convenient operation and stable lifting. It is used to lift heavy objects in mines, ports and building ...
Description QYZ Type Hydraulic Drilling Jar QYZ hydraulic drilling jar integrates upward jarring with downward jarring,It is a hydraulic type drilling jar.which is used in all kirds of well conditicn,it generates up and down jarring force by lifting and releasing drill stems ...
Style:Vertical Type:Circular Saw Model Number:YJ355-NCBT Brand Name:Jia cheng Place of Origin:China (Mainland) YJ-355 Full-auto hydraulic circular saw machine. PLC control. Auto sending material and sawing / cutting. ...
Style:Vertical Type:Circular Saw Model Number:YJ355-NCA Brand Name:Jia cheng Place of Origin:China (Mainland) YJ-355 Semi-auto hydraulic circular saw machine. PLC control. Auto sawing / cutting. ...
