Drilling Tools Integral Blade Stabilizer
Product Quick Detail
- Minimum Order
- 1
- Place Of Origin
- china
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Description
Integral Blade Stabilizer
HeKang provides integral straight blade stabilizer, integral spiral blade stabilizer, replaceable sleeve stabilizer, non-rotating stabilizer (rubber sleeve stabilizer), hard facing stabilizer,3-Piece sleeve replaceable stabilizer, float valve stabilizer, spherical stabilizer, variable diameter stabilizer, etc. All above products comply with API Spec 7.Integral 3-spiral blade stabilizer, integral 4-spiral blade stabilizer (string type, near bit type). The working hardfacing surface (also called as wall contact) materials available separately are carbide insert, insert diamond compound, low temperature brazing tungsten carbide slug,surface bead welding abrasive welding rod,etc.
Technical Specifications and Parameters
| (in) | (mm) |
End OD (mm) |
ID (mm) |
Kit Length (mm) | Connection | |||
| String type | Near bit type | |||||||
| Top | Down | Top | Down | |||||
| 6 | 152.4 | 121 | 51 | 1200 | NC38 | 3 1/2 REG | ||
| 6 1/4 | 158.7 | |||||||
| 6 1/2 | 165.1 | |||||||
| 7 1/2 | 190.5 | 159 | 57 | 1600 | NC46 | 4 1/2 REG | ||
| 7 7/8 | 200 | |||||||
| 8 3/8 | 212.7 | 159 165 | 71 | 1600 1800 | NC46 NC50 | |||
| 8 1/2 | 215.2 |
159 165 178 |
||||||
| 8 3/4 | 222.2 | |||||||
| 9 1/2 | 241.3 | 178 197 | 1600 | NC50 | NC50 | NC50 | ||
| 9 5/8 | 244.5 | 1800 | 6 5/8 REG | |||||
| 9 7/8 | 250.8 | |||||||
| 12 1/4 | 311.2 | 203 209 | 76 | 1800 | NC56 6 5/8 REG | NC56 6 5/8 REG | NC56 6 5/8 REG | 6 5/8 REG |
| 16 | 406 | 229 241.3 | 2000 2200 | NC61 7 5/8 REG | NC61 7 5/8 REG | NC61 7 5/8 REG | NC61 7 5/8 REG | |
| 17 1/2 | 444.5 | |||||||
| 24 | 609.6 | |||||||
| 26 | 660.4 | |||||||
| 28 | 711.2 |
Packaging & Delivery
- Packing :According to customer requirements
- Minimum Order :1 pieces
- Supply Ability :600 sets/year
- Country: China (Mainland)
- Business Type: Manufacturer
- Market:Americas,Emerging Markets,European Union
- Founded Year:2004
- Address:Highway East Road,Economic Development Zone,Dezhou
- Contact:ya mingdu
