| Engine |
|
| Bore Stroke | 90.0 mm (3.543 in) x 62.6 mm (2.465 in) |
| Compression Ratio | 11.3 : 1 |
| Engine | 4-stroke, liquid-cooled, DOHC |
| Fuel System | Fuel injection |
| Ignition | Electronic ignition (CDI) |
| Lubrication | Dry sump |
| Starter | Electric |
| Chassis |
|
| Brakes Front | Disc brake, twin |
| Brakes Rear | Disc brake |
| Color | White and Championship Yellow / Black |
| Curb Weight | 193 kg (425 lbs) |
| Final Drive | RK 520SMOZ10S, 96 links |
| Fuel Tank Capacity | 9.1 L (2.4/2.0 US/Imp gal) |
| Ground Clearance | 265 mm (10.4 in) |
| Overall Length | 1830 mm (72.0 in) |
| Overall Width | 1190 mm (46.9 in) |
| Seat Height | 810 mm (31.9 in) |
| Suspension Front | Independent, double wishbone, coil spring, oil damped |
| Suspension Rear | Swingarm type, coil spring, oil damped |
| Tires Front | AT22 × 7 R10 tubeless |
| Tires Rear | AT20 × 10 R9 tubeless |
| Transmission | 5-speed forward with reverse |
| Wheelbase | 1245 mm (49.0 in) |
| Warranty |
|
| Warranty | 12 month limited warranty. |
