SHACMAN F2000 Dumper Truck 6x4 Dump Trucks 340HP
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Product Description:
SHACMAN D’Long F2000 6x4 Dump Truck 340HP
MODEL: SX3254JS384
Traction type: 6X4
Driving type: LHD (RHD is optional)
Cabin: MAN cab, flat head, double doors, single sleeper with A/C
Engine brand: Steyr (Weichai)
Engine model: WD615.34
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line
with water cooling, turbo-charging & intercooling
Displacement: 9.726 liters
Max. output: 340hp@2200rpm
Max torque: 1350NM@1100-1600rpm
Bore/Stroke(mm):126/130
Gear box: Fuller 9 speeds (RT11509C) Fuller type
Clutch: Φ430 Diaphragm type
Steering: ZF technology
Front axle: MAN technology 7.5 ton front axle
Rear axle: Steyr strengthened axle (punching-welding axle housing, double
reduction driving axle, inter-wheel differential and differential lock)
Ratio=5.73
Tyre: 11.00-20
Spring: 9/12, 10/12
Fuel consumption (L/100km): 36
Fuel tank capacity (L): 380
Max. speed (km/h): 77
Max. gradeability(%): 25
Kerb. mass: 11200kg
Total mass: 25000kg
Wheel base (mm): 3800+1350
Front overhang (mm): 1525
Rear overhang (mm): 1600
Front track (mm): 1939
Rear track (mm): 1800
Approach angle: 16 degree
Departure angle: 66 degree
Dimension (mm): 8675x2490x3300
Body:
Inner size(mm): 5600x2300x1350
Capacity: 17.39M3
Thickness of body steel(mm): floor 8, side & back 6
Tipping type: middle tipping T type (underbody)
