Hebei Shuanghuan Conveying Equipment Manufacturing Co.,Ltd is a professional manufacturer of conveying equipment, covering an area of more than 60,000 square meters, with the registered capital of $ 200,000. Mainly engaged in designing and manufacturing bulk conveying system and equipment, we have specialized in manufacturing belt conveyor, conveyor roller, conveyor idler, conveyor pulley for 20 years.
Components of conveyor system:
1.Belt: Rubber or plastic belt.
2.Driving part: electronic motor, high speed coupling, speed reducer, low speed coupling, and all of the devices can be installed on a fixing bearing. Or using an electronic roller as a driving device.
3.Roller parts:Driving rollers and returning rollers.
4.Idler rollers parts: Trough idler rollers, parallel idler rollers, adjusting core idler rollers, and impact idler rollers , etc.
5.Intensity device: At the and of the belt to keep the belt work smoothly.
6.Unloading device: FIxed plow unloading device and electronic unloading vehicle.
7.Cleaning device: Elastic cleaning device in the front part, and empty segment cleaning device in the middle.
8. Brake device: Roller stopping device, Belt stopping device.
Specifications of conveyor system:
Belt width:
DTII(A)-type fixed belt conveyor takes belt width as its main parameter.Pls reference sheet 1-1.
Sheet 1-1 belt width series | ||||||
width/mm | (400) | 500 | 650 | 800 | 1000 | 1200 |
code | 40 | 50 | 65 | 80 | 100 | 120 |
width/mm | 1400 | (1600) | (1800) | (2000) | (2200) | (2400) |
code | 140 | 160 | 180 | 200 | 220 | 240 |
Note: specifications in bracket is ready to be developed.
