High Pressure Compressed Air Tank Professional Compressed Air Tank
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Air Tank, Compressed Air Tank, High Pressure Compressed Air Tank
Product Introduction chinacoal10
m.chinacoalintl.com
|
Design code: ASME VIII-1, PD 5500, API 650
Quality Rule: DNV, NORSKE, ISO 9001:2008 Special Material: Ti, Copper Nickle, Monel, Hastelloy Material: stainless steel and carbon steel |
|
1. Both inside and outside of the tank are blasted and rust removed by high speed
air flow, with best surface quality and service guarantee 2. The tank can be designed and different dimensioned by customer different requirements 3. Energy saving, buffer air 4. Certification of the pressure containe 5. DNV ISO9001:2008 & ASME Certificate:43097
|
|
Storage Tank(0.8—10 Mpa)
Compressed Air Storage Tank,Stainless Steel Storage Tank,High-pressure Storage Tank; Storage tank can store certain quantity of air,keep output air pressure stable,reduce temperature of air channel, and remove part of water, dust and impurities. |
Main Parameter
| Pressure Vessels & Tanks | |
| Design Code: | ASME VIII-1, PD 5500, API 650 |
| Diameter Range: | Up to 4 Meter |
| Length Range: | Up to 50 Meter |
| Pressure Range: | Up to 35 Mpa |
| Material code: | From ASME & ASTM |
| Available Material: | CS, SS, Alloy, High Alloy |
| Major Markets |
Refinery, Petrochemical, Chemical, Offshore, Pharmaceutical
,Marine Industries |
Adopt high quality material
| Material |
Mild
Steel |
Carbon Steel |
Low temperature
CS |
SS304/L | SS316/L |
| Plate | SA36 | SA516 Gr.70 | SA516 Gr.70 | SA240 304/L | SA240 316/L |
| Pipe | - |
SA106 Gr.B
/SA53-B |
SA333 Gr.1 / 6 | SA312 TP304/L | SA312 TP316/L |
| Tube | - | SA179 | SA179 | SA213 TP304/L | SA213 TP316/L |
|
Tube
sheet |
- | SA266 Gr.2 | SA350 LF2 CL.1 | SA182 F304/L | SA182 F316/L |
| Forging | - | SA105 | SA350 LF2 CL.1 | SA182 F304/L | SA182 F316/L |
| Fitting | - | SA234 WPB | SA234 WPB | SA403 WP304/L | SA403 WP316/L |
| Bolt | - | SA193 B7 | SA193 B7 | SA193 B8 | SA193 B8 |
| Nut | - | SA194 2H | SA194 2H | SA194 G8 | SA194 G8 |
