1.Features:
1)Hot dipped/electro galvanized, PVC coated
2)Specifications can be made according to your requests
2.Material:
Good quality low-carbon iron wire and stainless steel wire etc.
3.Assortments available:
Electro galvanized before weaving
Electro galvanized after weaving
Hot-dipped galvanized before weaving
Hot-dipped galvanized after weaving
PVC Coated mesh
Crimped wire mesh
Stainless Steel Square Wire Mesh
4.Application:
Square Wire Mesh is mostly used in as windows screening,safety guards on machinery enclosures.It's also widely used in filtering liquid andgas, sieving grain.
5.Inner packing:
Waterproof paper then shrink, or according to your requests.
Specification List of square wire mesh | ||
Opening | Aperture | |
Mesh inch | Wire dia. (mm) | |
2 | 1.60 | 11.10 |
4 | 1.20 | 5.15 |
5 | 1.00 | 4.08 |
6 | 0.80 | 3.43 |
8 | 0.60 | 2.57 |
10 | 0.50 | 1.99 |
12 | 0.50 | 1.61 |
14 | 0.45 | 1.36 |
16 | 0.40 | 1.19 |
18 | 0.35 | 1.06 |
20 | 0.30 | 0.97 |
30 | 0.25 | 0.59 |
40 | 0.20 | 0.44 |
50 | 0.15 | 0.35 |
60 | 0.15 | 0.27 |
Technical Note: 1,Available in width 0.60m-1.5m 3,Packing: in waterproof paper in rolls. Customer packing available at request. |
