Performance:
Flow range: 20 m3 / h ~ 180m3 / h
Head range: 8 ~ 20m
Motor power: 1.5kw ~ 22kw
Features
1. Double casings design centrifugal slurry pump, wide passage for solids;
2. Bearing assembly & frame: Both standard & high capacity typies available. A large diameter shaft with a short overhang minimizes deflection and
vibration. Heavy duty roller bearing are housed in a removable bearing cartridge. Pump body is fastened with the frame by minimum bolts. Impeller adjustment is provided in a convenient
position below the bearing assembly.
3. Impeller & liner material: high chrome white iron, etc.
4. Impeller type: open
5. Interchangeable wet parts material: High chrome alloy metal: PH: 5-12
6. Shaft seal: Packing seal, centrifugal seal, mechanical seal;
7. Discharge branch: 8 positions in each 45°;
8. Driving type: V-belt, flexible coupling, gearbox, hydraulic coupler, etc..
