specification:
rated loading 2000kg
rated bucket capacity 1.2m3
overall weight 5800kg
overall dimensions 4860×1900×1500mm
Maximum dump height 2622mm
Maximum dump reach 752mm
fuel capacity 80L
engine model YTR4108)
total time 9.2s
engine power 55kw
engine type in-line Direct injection Four-Stroke and Lnjection Chamber
function of leveling automacially YES
tyre specification 16/70—20
front tyre pressure 0.22Mpa
rear tyre pressure 0.18Mpa
options side dump truck,log gripper,fork,coal bucket,heavy duty bucket,air conditioner
specification: rated loading 3000kg rated bucket capacity 1.7-2.5m3 overall weight 9600kg overall dimensions 6890x2430x3070mm Maximum dump height 3100mm Maximum dump reach 1006mm fuel capacity 156L engine model YC6B125 engine power 96kw engine type Vertical, in-line, water ...
specification: rated loading 2000kg rated bucket capacity 1.2m3 overall weight 6000kg overall dimensions 5853x2000x2750mm Maximum dump height 2630mm Maximum dump reach 863mm fuel capacity 80L engine model YT4B2-GS3Q engine power 55kw engine type Vertical, in-line, water cooled, ...
specification: rated loading 1600kg rated bucket capacity 1m3 overall weight 4870kg overall dimensions 5182x1910x2712mm Maximum dump height 2330mm Maximum dump reach 800mm fuel capacity 80L engine model Huadong 4102 engine power 45kw engine type Vertical, in-line, water cooled, ...
