Supplier: Jiangyin Titan Machinery Equipment Co.,Ltd
Please confirm with the supplier: Model / reference, Key specifications / compatibility, Samples, Export markets, Supply capacity.
1. Application
Hydraulic Shear Press Q43-2000 is applied in steel mills, foundries, recycling plants, ferrous & non ferrous smelting industry to cold shear scrap metal into acceptable furnace charges. Hydraulic Shear Press Q43-2000 is suitable for angle steel, channel steel, steel sheet / plate, square billet, I-beam, round steel bar, deformed steel bar (rebar), steel pipe, miscellaneous section steel, metallic structural parts. Hydraulic Shear Press Q43-2000 is also good for non ferrous metal scrap such as aluminum extrusion profiles, thick copper cables, non ferrous metal sheets / plates, bars / rods, pipes / tubes, non ferrous alloys & structural parts, etc.
2. Features:
a, Fluid drive endows Y83 series with small size, light weight, low noise, high efficiency and many other advantages comparing to traditional mechanical drive.
b, Y83 provides option of auto and manual operation system. The tandem hydraulic cylinders increases the work speed and improves the production output.
c, Y83 series is designed and produced of a monothlic casting steel and this improves the stablability and lengthen the machine life.
d, The electrical part adopts imported PLC automatic control system which can reduce the malfunction ratio.
e, Y83 is widely used in different fields including scrap metal recycling industry and steel factory offering you qualified products.
3.Technical parameters:
|
Nominal force (KN): |
2000 KN |
|
Machine size (mm) : |
Main machine:2100*650*2100Oil box:1100*1100*700 |
|
Briquette size (mm): |
Φ 70~90 mm |
|
Briquette density (ton/m3) : |
≥ 5 ton/m3 |
|
Briquette frequency (kg) |
5 pcs/min |
|
Briquette weight (kg) |
1.5~2.7 kg/pc |
|
Power (kw): |
18.5 kw |
|
Nominal pressure: |
20 Mpa |
|
Operation: |
Manual/Automatic |
|
Output per shift (8 hours standard): |
3.5~6.5 t/shift (8 hours) |
4. ISO 9001:2008 Quality Management System
