1.Application:
Y81 series hydraulic metal balers (baling machine/compressor) are mainly used in steel manufacture, recycling companies, ferrous & non-ferrous smelting industry to press metal scraps (steel, copper, aluminum, stainless steel, discarded automobiles) into required shapes (cuboid, cylinder, octagon etc.), so as to reduce the transportation cost, to increase the speed of furnace feeding and reduce the furnace loss.
2. Features:
1)3-way compression, bale density is high.
2)Robust baler chamber of welding structure. Wear plates: standrad #45 steel (carbon steel), wholy heat treated; optional Mn65 steel wear plates. Cutting blades: optional.
3)Hydraulic oil cooler: standard water cooler (need cooling tower to supply cool water); optional normal air cooler, or compulsory air cooler (air cooler with compressor).
4)Magnetic return oil filter. NOK (Japan) seals for cylinders.
5)Hydraulic drive, manual valve operation, or Mitsubishi PLC operation.
6)Side ejection of finished bales. Loading hopper is optional for charging of material.
3.Technical parameters:
|
Nominal force: |
2000 (KN) |
|
Bale size: |
400*400 (mm) |
|
Bale density: |
≥ 2 t/m3 |
|
Bale discharging: |
Turn over & pust out optional |
|
Stuffing room(L*W*H): |
1800*1200*800 (mm) |
|
Production(per 8 hours): |
20-30 tons |
|
Cycle time: |
200 (s) single cycle |
|
Power: |
18.5 KW |
|
Nominal pressure: |
21 Mpa |
|
Operation: |
Manual/Automatic |
4. ISO 9001:2008 Quality Management System
