CT Analyzer
Product Quick Detail
- Wuhan Hubei
- China
- 2
- 1
- 1
- 1
- Packaging
- wooden case
- Delivery
- 7 days
Specifications
| Tests for Current Transformer: | Tests for Potencial Transformer: |
|
1 Excitation curve and parameters test
2 Turns ratio test
3 Ratio and phase error test
4 Polarity mark check
5 Winding resistance measurement
6 Secondary loop burden measurement
7 Error line curve test for protection CT
8 Transient CT parameters test
9 CT nameplate guess
10 Saturation hysteresis loop curve measurement
|
1 Turns ratio test
2 Ratio error and phase angle error test
3 Polarity test
4 Secondary burden test
5 Winding resistance test
|
|
1 CT nameplate check
2 CT parameters check in work burden
3 CT transient parameters analysis
4 CT ratio and phase error calibration
5 PT routine test
|
- Country: China (Mainland)
- Business Type: Manufacturer,Distributor/Wholesaler,Retailer
- Market:Americas,Europe
- Founded Year:1997
- Address:4F,B7,Optical Valley International Headquarters Industrial Park,No.62,Optical Valley Rd, Wuhan,China,430074
- Contact:Shuyue Wang
