small portable water well drilling rig

Product Introduction

1. borehole water well drilling machine Appliance :

a. Keeping bracket is installed on the hoist to form a double wheel support structure, able to withstand

strong blow

b. Vertical box are fixed by four groups of bearings to ensure that the rotary machine has sufficient rig

idity to overcome gravel layer and other complex geological conditions.

c. the machine is equipped with national patent technology---

taper clutch, with characteristics of strong transmission torque, easy operation and free maintenance

d. drilling rod adopted, high rigidity and strong delivery torque.

2. borehole water well drilling machine Feature:

1.drilling rig is mainly used for geological general investigation and exploration, road and tall building

foundation exploration.

2. kinds of hole in concrete structure, river levees, subgrade grouting hole ,drilling and direct grouting,

civil wells and earth temperature central air-conditioner,etc

Technology Parameters

Unity machine parameter
Drilling depth	10-130m
Maximum open hole caliber	260mm
End hole caliber	75mm
Drill rod caliber	50mm
Drilling angle	90~75
Drill weight (No include power)	510 560kg
Unity machine dimensions	2.5×1×1.3 2.5×0.9×1.3m
Spindle
spindle speed	142,285,570r/min
Spindle stroke	450mm
Hoist
Max.single line hoisting capacity	960kg
Single line lifting speed	0.41,0.82,1.64m/s
Tightrope caliber	27m
Mud pump of HZ-130YY model drilling rig
Type	Horizontal single urn twin-action
Displacement	95/77L/min
Diesle engine	Model s1110 18HP
Electric motor	Y160M—4 11kw 1440r/min
Maximum pressure	1.2Mpa
Work pressure	0.7Mpa
Water inlet caliber	30mm
Water to exit caliber	25mm
Triangle conveyor belt	B1575mm

Remarks: We have many types of drill rig . For 100meters,200meters,300meters,500meters,1000meters,2000meters,any question will be apppreciated.
