1.Product specification:
Stardard size: 595*595mm, 595*1, 195mm, 603*603mm, 603*1212mm.
Thickness: 7mm, 7.5mm, 8mm, 8.5mm, 9mm, 9.5mm.
Size tolerance: Length ± 2mm, width ± 2mm, thickness: ± 0.5mm
Weight: 6-7.5kg/sqm
2.Application:
Shijiazhuang TengChuang Building Materials Co.,LTD is one of the construction materials manufactures inChina.
Our PVC gypsum ceiling board is used in indoor decoration such as hotel,hostipal,school,factory etc. It's fireproof,
heat insulation,beautiful design,high intensity and high-strength,non-dust. We have more than 200 patterns design
3.Technical performance
Materials: Gypsum Board
Surface: PVC Aluminum Foil
Allow Dimension Difference:
Length <2.0mm
Width <2.0mm
Thickness <0.5mm
Weight Kg/ m2: < 6.5kg/m2
Strength: Break Load>150N
Containing Water Rate: < 1%
Fireproof Class: Class B1
Meet the standard: GB8624-1997
Moisture Requirement: Under 90%
