Power
|
|
Input voltage
|
+12 VDC or Power-over-Ethernet (AC24V option)
|
|
Power consumption
|
6 W (max)
|
|
Video
|
|
Sensor type
|
1/2.8 Type SONY Exmor CMOS Sensor
|
|
Sensor pixels
|
1920x1080
|
|
Sensitivity
|
0.2 lx (IR off) 0 lx (IR on)
|
|
Main-stream Resolution
|
1920x1080 @25fps; 1280*720@25fps
|
|
Sub-steam Resolution
|
4CIF@25fps; CIF@25fps
|
|
Video compression
|
H.264 MP (Main Profile)
|
|
Night vision
|
|
Distance
|
20 m
|
|
LED
|
24 LED high efficiency array, 850 nm
|
|
Lens
|
|
Lens type
|
Motorized 2.8 to 12 mm lens
|
|
Field of View
|
H: 85°- 26°
|
|
Lens mount
|
Board mounted
|
|
Day & Night
|
Auto ICR Switch (IR correction filter)
|
|
Connection
|
|
Analog video out
|
N/A
|
|
Alarm input (optional)
|
1 alarm in
|
|
Alarm out (optional)
|
1 alarm out
|
|
Audio (optional)
|
|
Audio input
|
RCA jack connector
|
|
Audio output
|
RCA jack connector
|
|
Audio communication
|
Two-way, full duplex
|
|
Audio compression
|
G.711 (live and recording)
|
|
Local Storage (optional)
|
|
Memory card slot
|
Supports up to 32 GB micro SD card (An SD card of Class 8 or higher is recommended for HD recording)
|
|
Recording
|
Continuous recording, Motion/schedule recording
|
|
Software Control
|
|
Unit configuration
|
Via web browser or PC surveillance software
|
|
Network
|
|
Protocols
|
HTTP, TCP/IP,ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, 802.1x
|
|
Ethernet
|
10/100 Base-T, auto-sensing, half/full duplex, RJ45
|
|
Wireless
|
N/A
|
|
PoE
|
IEEE 802.3af compliant
|
|
Mechanical
|
|
Dimensions
|
Diameter: 132 mm Height: 105 mm
|
|
Weight
|
TBA
|
|
Environmental
|
|
Operating temperature Camera
|
-20 ºC to +55 ºC (-4 ºF to +131 ºF)
|
|
Storage temperature
|
-20 ºC to +70 ºC (-4 ºF to +158 ºF)
|
|
Humidity
|
10% to 80% relative humidity (non condensing)
|
|
Ordering Information
|
|
IR IP Dome MF 2.8 to12mm lens on-board storage,
|
2250
|
|
IR IP Dome MF 2.8 to 12mm lens
|
2251
|
