Strenghts for platinum cure molding rubber silicone rtv

Platinum cure molding rubber silicone rtv is used for prototyping and the reproduction of parts. Silicone moulds can be constructed in many different forms depending on the shape of the part you are making. In this section we will outline how to create the easiest one part flat back mould.

Why platinum cure molding rubber silicone rtv

Silicone is the first choice of material when casting 3 dimentional shapes that contain undercuts as it exhibits excellent release properties, a high level of surface detail, very good chemical and high temperature resistance.

It comes in a two-component system (base + catalyst) available in a hardness range of very soft to medium. It is available for making moulds that are poured, brushed or sprayed

Features of platinum cure molding rubber silicone rtv

1. Good characteristics of easy-operation

2. Light viscosity and good flowability

3. Low shrinkage

4. Favorable tension

5. No deformation

6. Favorable hardness

7. High temperature resistance, acid and alkali-resistance and ageing resistance

8. Food grade, non-toxic

Datasheet of platinum cure molding rubber silicone rtv

Model Color Mixing ratio Pot life (mins) Demouled time (hrs) Hardness (A0) Tensile-strength (kgf / cm2) Tear-strength (kgf / cm) Viscosity (cps) Elongation (%)

HY-E625 translucent 1: 1 30-60 4 ± 1 25 ± 2 35 ± 2 25 ± 2 6000 ± 3000

HY-E630 translucent 1: 1 30-60 4 ± 1 30 ± 2 40 ± 2 23 ± 2 7000 ± 3000

HY-E635 translucent 1: 1 30-60 4 ± 1 35 ± 2 47 ± 2 22 ± 2 8000 ± 3000
