GFAK type FRP hydrochloric acid tank vehicle. This vehicle whose tank body is made of FRP is a tank vehicle for railway which can transport specific weight =1.2 hydrochloric acid medium. This vehicle is composed of chassis, tank body, vehicle hook buffer mechanism and bogie. The chassis underframe has middle girder. The inside diameter of the roll tank is 2600mm. The tank is made of FRP which is composed of the anticorrosion layer, the load bearing layer and aging resistant layer, and can resist corrosion and keep clean. The tank is equipped with exhaust stack and blast pipeline. The loading and unloading way is top loading and unloading (manhole is also used to load acid medium). Vehicle hook buffer mechanism, arresting gear, bogie, ST buffer; 120 air control valves, ST2-250 bidirectional brake shoe gap automatic regulating apparatus, KZW-4GAB or TWG-1A spatial car or machine with load automatic control installment, the K2 bogie. The user can also select the horizontal chain type hand brake or the NSW hand brake, the carbon steel brake fitting piping (to phosphorize in piping) or the stainless steel brake fittings piping to install.
Main technique parameters of GFAK type FRP tank vehicle | ||
load | t | 62 |
deadweight | t | 19.7 |
total capacity | m3 | 53.7 |
valid capacity | m3 | 51.7 |
working pressure of tank body | MPa | 0.15 |
vehicle length | mm | 11988 |
business operation speed | km/h | 120 |
The FRP Twisted Septic Tank is an innovative solution for wastewater treatment, ideal for areas without central sewage. Its unique design is practical and efficient, making it durable and adaptable for both residential and commercial uses in various environments.FRP Twisted ...
FRP MSC Septic Tanks deliver advanced wastewater management for residential to industrial uses, especially in areas lacking centralized sewage. These corrosion-resistant, leak-proof tanks are suitable for diverse environments, offering reliable, long-lasting sewage treatment and ...
SMC Water Tanks, made from fiberglass reinforced plastics, are modular, lightweight, rustproof, and durable. Ideal for hotels, schools, hospitals, and mines, they offer on-site assembly with capacities from 0.125m³ to 125,000m³, suiting various needs. Hengshui Hongwo ...
Product Name: Double wall spraying (winding) production line Production line composition: The production line mainly consists of a walking machine head, a tail of a walking machine, a spraying trolley, spray gun, and control system. 1. Tank diameter: DN1000-3000mm 2. Tank ...
1.Water distributor used for water treatment. 2.High chemical resistance and pressure operation. 3.Max diameter of the tank can reach 1800mm 4.Pressure-bearing of tank : 1 MPa 5.Operating temperature : 40 centigrade ...
Specification: 1.Size:0613-7294 2.Maxmium working pressure: 1.0MPa(150PSI) 3.Material : FRP and PE 4.Working Temperature :1-49Centigrade 5.Maximumvacuum : 127mmHg(5\"Hg). 6.Certificates: CE ;NSF ; ISO9001 etc. 7.Warranty: 3 years 8.Application: All feed water and waste water ...
FRP filter system can be widely used sewage and wastewater reuse, desalination, electronics and other fields. It is character with high flow, long working life and good operation of complex liquid. It consists of the housing and the cartridge. It can install high flow cartridge ...
Product Description: A water softener is a resin chemical base water treatment system which is uses to make soft water by removing \"hardness\"from the raw water. The “Hardness” means over containing of calcium and magnesium dissolves in to the raw water. It is design ...
FRP transportation tank, also named FRP transportation vessel, is made of resin and fiberglass with filament winding process by microcomputer control machine. Commonly being horizontal, FRP transportation tank with saddles is applied to transport highly corrosive liquid, gas and ...
FRP water storage tank (or FRP water storage vessel), a once shaping vessel, adopts high-strength acid and alkali resistant materials, including organic resin and fiberglass. It has excellent performance in filtering waste particles and pungent odor. Meanwhile, it has the ...
