| Camera | Sensor | 1/2.8"sony 2.3 Megapixel CMOS |
| | Effective pixels | 1920×1080 |
| | Scan mode | Progressive scanning |
| | Resolution | 1080p/60, 1080p/50, 1080p/30, 1080p/25, 720p/60, 720p/50 |
| | WDR | Digital WDR |
| | Min. Illumination | Color:1.0lux,BW DSS:0.008lux |
| | Lens | C/CS interface |
| | WB | Auto / Auto Tracking / Indoor / One-Touch / Manual |
| | S/N ratio | >50 dB |
| | WDR | Auto / Manual (Off / On) |
| | Day/Night mode | Auto ICR filter color to black |
| | DNR | Support 3D DNR |
| | AGC | Auto/Manual |
| | Sync mode | Internal and external synchronization |
| | Defog | Support |
| | Control mode | Support RS485 |
| | Menu | OSD |
| Others | Power supply | DC12V |
| | Work temp | -30°C to 60°C , 0～95% humidity（no condense） |
| | Installation | Wall |
| | Size | 50 x 50 x 100mm |
